Key Features:
1) High energy density, high and stable operating voltage, with average voltage over 3.7V.
2) High safety, no fire, no explosion.
3) Long cycle life over 800 times.
4) Battery can be designed into different shapes and sizes.
5) Environmental friendly.
6) Customized designs are available，with thickness from 0.2 to 2mm, capacity from 5 to 2000mAh.
Notice: Since many models are created in every months, and may not timely update in the following table. When you can not find out your battery, please contact us to ask solutions. When you find the batteries you want, pls also ask us for price and further information.
| Model |
Nominal Voltage (V) |
Capacity (mAh) |
Dimension(mm) |
Datasheet |
||
| Thickness(±0.2) | Width(±0.5) | Length(±0.5) | ||||
| FTN-P081518 | 3.7V | 5mAh | 0.8 | 15 | 18 | Please contact us |
| FTN-P042040 | 3.7V | 8mAh | 0.4 | 20 | 40 | |
| FTN-P091525 | 3.7V | 15mAh | 0.9 | 15 | 25 | |
| FTN-P151530 |
3.7V | 20mAh | 1.5 | 15 | 30 | |
| FTN-P013040 |
3.7V | 70mAh | 1.0 | 30 | 40 | |
| FTN-P013050 |
3.7V | 100mAh | 1.0 | 30 | 50 | |
| FTN-P013945 |
3.7V | 110mAh | 1.0 | 39 | 45 | |
| FTN-P015836 |
3.7V | 120mAh | 1.0 | 58 | 36 | |
| FTN-P014750 |
3.7V | 150mAh | 1.0 | 47 | 50 | |
| FTN-P015253 |
3.7V | 180mAh | 1.0 | 52 | 53 | |
| FTN-P015362 |
3.7V | 180mAh | 1.0 | 53 | 62 | |
| FTN-P135836 |
3.7V | 190mAh | 1.3 | 58 | 36 | |
| Custom model |
/ | / | / | / | / | |
